NUEMA PATIO DOORS

$CALL FOR QUOTE OR FAX A WINDOW LIST -831-753-0405 FAX

SPECIAL ORDER
Wood-Pine Growing Right Arrow 1
NUEMA FIBERGLASS FRENCH AND PATIO DOORS
NEUMA PATIO DOORS SPECIAL ORDER


SMOOTH SKIN PAINT ONLY
SIMULATED WOOD GRAIN TEXTURED SKIN PAINT OR STAIN GRADE
(YOU MUST FOLLOW FINISH INSTRUCTIONS FOR FIBERGLASS DOORS AND USE ONLY PRODUCTS FOR FIBERGLASS DOORS)
5-0 X 6-8

6-0 X 6-8


Design Features



Retractable Screen
Conventional screens and smooth operating retractable screens are available. Engineered retractable screens are optional.



Weep Hole
A weep-hole cover is provided which allows water to drain out, while preventing dust and dirt from getting in.



Securing Plate

Bottom Wind Stopper

Stainless Roller
Adjustable stainless tandem rollers are installed in the active panel.







Frame

  • Composite frames come standard in a smooth finish,woodgrain is available upon request.
  • Interior woodgrain is standard. Optional exterior woodgrain finish is available by special order.
  • Frames are available in 4-9/16”, 6-9/16”.
  • Stainless steel sill track to reduce friction and prevent corrosion.
  • Specially designed weep-hole covers allow water to drain away from the door while keeping dust and dirt out.
  • Our superior weather stripping offers excellent air/water tightness to the entire unit.







Panel

  • The polyurethane foam core is 100% CFC-free.
  • Doors come standard with the smooth white finish, wood grain is available upon request.
  • Full-length composite stile and rails increase water and moisture protection.
  • The interlock has dual flexible strips to seal the gap between panels.
  • Stainless tandem rollers under the active panel are adjustable for better installation.





Hardware & Glazing

  • Our standard doors come with 5/8” insulated Low EČ 272 glass. Impact rated doors come with 1” impact glass (Laminated). Co-extruded glass stopper provides easy glass replacemen.
  • Standard Lock systems are installed on 6’8” and 6’11” doors (multi-point locks available on request)
  • The multi-point lock system installed standard on all 8’ height doors.
  • Retractable screens have been specially designed for Neuma Doors.
Multi-Point Lock

Patio door lock sets are available for greater security; multi-point locks are standard on 8’ height doors and optional on 6’8” and 6’11” doors.





Hardware Color Option





Handle Set Option - Left Side

All handle options are available with Gold Brass, Satin Nickel, White and Dark Brown finish.

Note: For coastal exposure areas, our hardware in the HPVD coating is standard with all our impact rated doors; with Stain Nickel or Gold Brass finishes.
(* HPVD: High Performance; Physical; Vapor; Deposition



CLICK HERE FOR PDF FILE NEUMA GLIDING PATIO DOOR SPECIFICATIONS

831-753-7521

831-753-7521


OPERABLE VENT SIDELITES

Design Features

  • Frame components are made of composite materials with a smooth paintable or stainable finish on the exterior.
  • Smooth paintable or stainable woodgrain finishes are available.
  • Fiberglass skins on panels are strong, durable and will not rust, dent, split or rot.
  • Thresholds have an engineered drainage system to channel water away from the unit.
  • Hardware finishes are available in Gold Brass, Satin Nickel, White and Dark Brown
  • The sidelights on the patio door include flat removable screens
    (Screens are removable for cleaning.)
Vented sidelights feature a 3-point latch locking system with a craft-designed thumb-turn.







Panel




  • WARRANTY
  • CLICK HERE FOR NEUMA PDF FILE SPECIFICATIONS

    CLICK HERE FOR PDF FILE TEST RESULTS NEUMA PATIO DOORS

    831-753-7521 CALL FOR QUOTE

    • Design Features



    Multi-Point Lock

    Our superior, multi-point lock system increases security and enhances performance by providing smooth operation. The multi-point lock is standard on all 8’ units.



    Glass Option
    Our standard doors come with 5/8” insulated Cardinal Low E2 272 glass. Impact rated doors come with 1” impact glass (Laminated). Co-extruded glass stopper provides easy glass replacement. All units are available with internal grilles.



    Aluminum Mullion Retractable Screen
    Our durable aluminum mullion, covered with composite material, can withstand strong winds and heavy rains. Engineered retractable screens are optional.



    Weep - Hole
    A weep-hole cover is provided which allows water to drain out, while preventing dust and dirt from getting in.



    Frame

    • Frames are made of composite material with a smooth exterior and interior finish
    • Optional woodgrain finish is available. Exterior woodgrain is special order
    • Frames are available in 4-9/16” or 6-9/16”*
    • Jambs include screen channels
    • Thresholds have superior draining systems to channel water away from the door







    Panel

    • Pre-finished woodgrain doors are available in a wide variety of colors.
    • Smooth surfaces can be painted and textured surfaces can be stained
    • The polyurethane foam core is 100% CFC-free
    • Standard doors have smooth white exterior and smooth white interior
    • Optional woodgrain textures are available. Exterior woodgrain is special order
    • Strong and durable fiberglass skins will not rust, dent, split or rot
    • Full-length composite edging increase water and moisture protection
    • The bottom sweeps have superior weather stripping design
    * Net Jamb dimensions are 5-3/4” and 7-3/4”





    Hardware & Glazing

    • Multi-point lock systems are available for all patio systems, standard on 8’ patio doors.
    • Dark Brown and Gold Brass handle sets come with matching sills. Satin Nickel and White handle sets come with an anodized aluminum sill.
    • All hardware components are precisely designed and machined for Neuma Doors.
    • Handle sets are available with a Gold Brass, Satin Nickel, White or Dark Brown finish.




    Standard lock system

    Precision-engineered latches and
    deadbolt.




    Multi-point lock system

    Stainless steel plates provides excellent corrosion resistance, enhances performance, ensures smooth operation and offers the best security, available in Satin Nickel and brass only.





    Hardware Color Option





    Handle Set Option - Style & Finish

    All handle set finishes are available for both the Tiffany and Royal series. Hardware finishes are available in Gold Brass, Satin Nickel, White and Dark Brown. Handle colors come with matching sills, with the exception of white handles, which have anodized aluminum sills.

    Note: For coastal exposures, our impact rated doors have hardware with HPVD coating (* HPVD: High Performance; Physical; Vapor; Deposition). These are available only in the Royal series, with either Satin Nickel or Gold Brass finish.



    Warranty











    CLICK HERE FOR PDF FILE TEST RESULTS HINGED PATIO DOORS

    CLICK HERE FOR PDF FILE SPECIFICATION HINGED NEUMA PATIO DOOR

    CLICK HERE FOR PDF FILE INSTALL INSWING HINGED NEUMA PATIO DOOR

    CLICK HERE FOR PDF FILE INSTALLATION OUTSWING NEUMA HINGED PATIO DOOR
